Mini Barcode Scanner 1D 2D Bluetooth Protable Scanners Bar Code Reader YHD-3600DB
Convenient to switch between 2.4G wireless & Bluetooth & USB wired three types of connection mode. YHD-3600DB Scanner delivers up to 100m transmission distance in barrier free under the 2.4G wireless mode, up to 10m transmission distance barrier free under the Bluetooth mode.
Features
● Mini size, light and portable.
● Plug & Play, Drive free.
● Support multi keyboard language.
● Support Bluetooth-HID/SPP/BLE and can be switched
● Support Bluetooth/2.4G/Wired and can be switched.
● 16M internal storage can store around 100,000 barcode under storage mode.
● Support for smart phones/tablets/computers; compatible for Windows /Android /IOS.
● Supermarket, Retail, Warehouse,Logistic,Library, Tobacco, Medical etc.
● Can be customized according to customer demand.
Technical parameters
Working current : 3.5 V ± 10%x100mA
Light source : 617LED
Sensor : 640*480 CMOS lumination : 6500K LEDs
CPU : ARM 32-bit Cortex
Decoding speed : 500/sec
Depth of Filed : 30-600mm
Indication : Buzzer & LED
Decoding accuracy : ≥4mil
Trigger Mode : Button,Continuous,Auto-Induction
Printing Contract : ≥25%
Scanning angle : Angle of rotation±360°,inclination± 65°,declination ± 60°
Anti-interference : 0-100000Lux Max
Decode Capability :
1D : UPC-A,UPC-E,EAN-8,EAN-13,Code 128,Code 39,Code 93,
Code 11,Interleaved 2 of 5,Matrix 2 of 5,Standard 2 of 5(IATA),
Coda bar(NW-7),MSI Plessey,ISBM,ISSN,China post etc.
2D : QR Code, Data Matrix, PDF417, Aztec code, Maxicode,etc.
Button life : 10000,000 times
LED life : 100000 hours
Drop test : 1.8m
Relative humidity : 5%-95%
Working temperature : -20℃ to 50℃ Charging power : 5V-400mA
Transmission mode : Bluetooth / 2.4G Wireless / USB Wired
Transmission distance : 10m /100m / 1.5m
Battery : 3.7V-1200mAh
Working mode : Instant upload mode,Storage mode,Not lost mode
Storage : 16MB≈100,0000 barcodes
Working time : Full load≈15hours,Normal use ≈3 to 8days
Certificate : CE,FCC,ROHS,IP54,FDA,SGS
Packaging Details
Standard List: Scanner *1, Charging Cable *1, Receiver*1, Manual *1 ,Sling* 1, Box* 1
Single Package Size: 160*100*35mm
Single Gross Weight: 0.15kg
50pcs/CTN Carton Size: 530*195*340mm
50pcs/CTN Carton G.W.:9.2Kg, N.W:7.2Kg
